180157 - Edge Rounding Cutters HW two-part version - IMA (BIMA)
Technical data
Description
Machine / Application
- edge banding machines IMA model BIMA with glueing device / flush cutting unit 6135
- for rounding and flush-cutting of solid wood, veneer and plastic edge bands
Design
- two part version
- with shear angle
- n max = 18,000 min-1
Advantages
Notes
- sense of rotation see drawing
Feature | Value | |
---|---|---|
R = Radius | 2,0 [mm] | |
Ø D = Cutting circle diameter | 70 [mm] | |
B = Cutting width | 9,0 [mm] | |
b = Hub width | 9 [mm] | |
Ø d = Bore diameter | 30 [mm] | |
Z = No. of teeth | 6 | |
nmax = maximum RPM | 18,000 [min-1] | |
L/R = cutting direction | L | |
L = Delivery Status | ||
Machine/Type | IMA (BIMA) | |
Dimensions entered are not listed?
available from stock |
