Mounting Flanges for Clamping System Ø 110 mm - tools with bore d=30 mm
Article
Description
Machine / Application
- for mounting of light tools with bore Ø 30 mm, 6 countersunk holes for M 5, TK Ø 90 mm
Design
Advantages
Notes
- for clockwise and counter-clockwise rotation
- at least two separate tool/flange assemblies should be used per clamping element (reduced downtimes)
Ø d1
[mm] |
L2
[mm] |
L
[mm] |
Ø D
[mm] |
L1
[mm] |
Ident-No. | Comp./ Inqu. | |
---|---|---|---|---|---|---|---|
Dimensions entered are not listed?
available from stock |
|||||||
30 | 15,5 | 10 | 110 | 40 | 163705 | ||
30 | 15,5 | 10 | 110 | 40 | 163226 |
