Panel Sizing Saw Blades HW - Q-Cut "G5"
Product
Drawing
-
-
- Tungsten Carbide [HW]
-
Article
Description
Machine / Application
- horizontal panel sizing saws
- for sizing and finish cuts in wood core plywood, plywood boards, veneered or paper-laminated wood-based panels and honeycomb panels
Design
- vibration and noise damping ornaments
- additional expansion slots
- tooth configuration: G5
- cutting material: HW HL Board 04 plus
Advantages
- very low cutting pressure and small power consumption thanks to optimized cutting geometry
- excellent cutting quality in wood-based materials containing fibers
- extremely low-noise and smooth running thanks to vibration and noise damping ornaments as well as special expansion slot combinations
Notes
- Attention: when assigning the appropriate scoring saw blades, please take into account the cutting width reduction of 4 mm!
- NL**- Combi3 = 2/10/60 + 2/9/46 + 2/9.5/46.5 + 2/7/42
- NL**- Combi5 = 2/7/110 + 2/9/110 + 2/8.4/130 + 2/14/110 + 4/9/100 + 4/19/120
- NL**- Combi7 = 2/9/110 + 2/10/80 + 2/11/85 + 2/11/115 + 2/11/148 + 2/14/100 + 2/14/125 + 2/19/120
|
Ø D
[mm] |
B
[mm] |
b
[mm] |
Ø d
[mm] |
Z | NL |
Hook angle
[°] |
Shear∡
[°] |
Tooth geometry | LEUCODUR | Machine/Type | Ident-No. | Comp./ Inqu. | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Dimensions entered are not listed?
available from stock |
|||||||||||||
| 300 | 4,0 | 3.2 | 30 | 100 | 2/10/60 + 2/9/46 + 2/9,5/46,5 + 2/7/42 | 15 | 8 | G5 | HL Board 04 plus | Fimal Concept 350 | 193312 | ||
| 350 | 4,0 | 3.2 | 30 | 80 | 2/10/60 + 2/9/46 + 2/9,5/46,5 + 2/7/42 + 2/13/94 | 15 | 8 | G5 | HL Board 04 plus | SCM, Panhans, Mayer, Schelling, HOLZ-HER | 192813 | ||
| 350 | 4,0 | 3.2 | 60 | 80 | 2/9/110 + 2/10/80 + 2/11/85 + 2/11/115 + 2/11/148 + 2/14/100 + 2/14/125 + 2/19/120 | 15 | 8 | G5 | HL Board 04 plus | Homag (Holzma) | 192814 | ||
| 380 | 4,0 | 3.2 | 60 | 80 | 2/9/110 + 2/10/80 + 2/11/85 + 2/11/115 + 2/11/148 + 2/14/100 + 2/14/125 + 2/19/120 | 15 | 8 | G5 | HL Board 04 plus | Homag (Holzma) | 192815 | ||
| 400 | 4,0 | 3.2 | 30 | 85 | 2/10/60 + 2/9/46 + 2/9,5/46,5 + 2/7/42 + 2/13/94 | 15 | 8 | G5 | HL Board 04 plus | 192816 | |||
| 430 | 4,0 | 3.2 | 30 | 85 | 2/10/60 + 2/9/46 + 2/9,5/46,5 + 2/7/42 + 2/13/94 | 15 | 8 | G5 | HL Board 04 plus | 192817 | |||
| 430 | 4,0 | 3.2 | 80 | 90 | 2/7/110 + 2/9/110 + 2/8,4/130 + 2/14/110 + 4/9/100 + 4/19/120 | 15 | 8 | G5 | HL Board 04 plus | Selco | 192818 | ||
| 450 | 4,0 | 3.2 | 60 | 90 | 2/9/110 + 2/10/80 + 2/11/85 + 2/11/115 + 2/11/148 + 2/14/100 + 2/14/125 + 2/19/120 | 15 | 8 | G5 | HL Board 04 plus | Homag (Holzma) | 192819 | ||
| 460 | 4,0 | 3.2 | 30 | 90 | 2/13/94 | 15 | 8 | G5 | HL Board 04 plus | Schelling | 192820 | ||
