187605 - Finger Joint Cutters HS topcoat 104
Product
Drawing
-
- High Speed Steel [HS]
- MEC
Technical data
Description
Machine / Application
- finger joint machines
- machines with cross-cutting device
- For longitudinal joints in soft, hard and exotic woods, with a finger length of 20 mm
Design
- Finger length of 20 mm
- HS suitable for soft woods
- HS Solid 34 suitable for knotty soft woods
Advantages
- HS Solid 34: high bending strength, compared to HS finger joint cutters the edge life is 1.5 - 2 times as long
- topcoat 104: the edge life is 2 times as long compared to HS finger joint cutters
Notes
| Feature | Value | |
|---|---|---|
| Ø D = Cutting circle diameter | 180 [mm] | |
| B = Cutting width | 33 [mm] | |
| b = Hub width | 31 [mm] | |
| Ø d = Bore diameter | 50 [mm] | |
| Z = No. of teeth | 2+2 | |
| Partition = Partition | 6.2 [mm] | |
| Finger joint length = Finger joint length | 20/22 [mm] | |
| Number of finger joints = Number of finger joints | 5 [pc.] | |
| nmax = maximum RPM | 8,000 [min-1] | |
| L = Delivery Status | ||
| Remarks | HS, topcoat 104 | |
|
Dimensions entered are not listed?
available from stock |
||
