180163 - Edge Chamfering Cutters HW two-part version - IMA (BIMA)
Product
Drawing
-
- Tungsten Carbide [HW]
- MEC
Technical data
Description
Machine / Application
- edge banding machines IMA model BIMA with glueing device / flush cutting unit 6135
- for flush-cutting and chamfering of solid wood, veneer and plastic edge bands
Design
- with shear angle
- two part version
- n max = 18,000 min-1
Advantages
Notes
- sense of rotation see drawing
| Feature | Value | |
|---|---|---|
| Chamfer∡ = Chamfer angle | 30 [°] | |
| Ø D = Cutting circle diameter | 70 [mm] | |
| B = Cutting width | 9,0 [mm] | |
| b = Hub width | 9 [mm] | |
| Ø d = Bore diameter | 30 [mm] | |
| Z = No. of teeth | 6 | |
| nmax = maximum RPM | 18,000 [min-1] | |
| L/R = cutting direction | R | |
| L = Delivery Status | ||
| Machine/Type | IMA (BIMA) | |
|
Dimensions entered are not listed?
available from stock |
||
