Mounting Flanges for Clamping System Ø 110 mm - saw blades d=50 mm
Article
Description
Machine / Application
- for the mounting of saw blades up to Ø 250 mm and saw plate thickness 1.8 - 2.2 mm with bore Ø 50 mm, 3 NL - Ø 22 mm, TK Ø 80 mm
Design
Advantages
Notes
- for clockwise and counter-clockwise rotation
- especially suited for the mounting of scoring saw blades
Ø d1
[mm] |
L
[mm] |
Ø D
[mm] |
L1
[mm] |
Ident-No. | Comp./ Inqu. | |
---|---|---|---|---|---|---|
Dimensions entered are not listed?
available from stock |
||||||
50 | 10 | 107 | 26.5 | 160849 |
