192422 - Scoring Saw Blades DP - adjustable "WS"
Product
Drawing
-
- Polycrystalline diamond [DP]
Technical data
Description
Machine / Application
- table saws
- for chip-free scoring of melamine-, paper- or HPL-laminated panels
Design
- tooth configuration: alternate top bevel "WS"
Advantages
Notes
- application with feed
- split version - cutting width adjustable with spacers
- Ident-No. 189104 automatic kerf adjustment
- X = for Striebig "Compact", "Evolution", "Control", adjustable by means of spring ring and attachment screw
| Feature | Value | |
|---|---|---|
| Ø D = Cutting circle diameter | 120 [mm] | |
| B = Cutting width | 2,8-3,6 [mm] | |
| b = Body thickness | 2.2 [mm] | |
| Ø d = Bore diameter | 20 [mm] | |
| Z = No. of teeth | 2x12 | |
| NL = Pin holes | 2/3,2/42 | |
| Hook angle = Hook angle | 8 [°] | |
| Tooth geometry = Tooth configuration | ES | |
| L = Delivery Status | ||
| Machine/Type | SCM | |
|
Dimensions entered are not listed?
available from stock |
||
