189876 - DIAREX NF-Chop Saw Blades DP - Solid "TR-F-FA"
Product
Drawing
-
-
- Polycrystalline diamond [DP]
-
Technical data
Description
Machine / Application
- chop and miter saws
- for miter cuts in solid aluminum materials
Design
- neutral hook angle
- tooth configuration: inverted-v / flat with chamfer "TR-F-FA"
Advantages
- excellent burr-free cuts with low roughness thanks to special laser ornaments and tooth partition
Notes
- tight workpiece clamping required
| Feature | Value | |
|---|---|---|
| Ø D = Cutting circle diameter | 550 [mm] | |
| B = Cutting width | 4,4 [mm] | |
| b = Body thickness | 3.8 [mm] | |
| Ø d = Bore diameter | 50 [mm] | |
| Z = No. of teeth | 96 | |
| NL = Pin holes | 4/15/80 | |
| Hook angle = Hook angle | 0 [°] | |
| Tooth geometry = Tooth configuration | TR-F-FA | |
| L = Delivery Status | ||
| Machine/Type | Kaltenbach RKL 550 | |
|
Dimensions entered are not listed?
available from stock |
||
