EcoLine Through-Hole Bits HW

Product

Drawing

  • Tungsten Carbide [HW]
  • MAN

Article

Description

Machine / Application

  • portable boring machines
  • automatic boring machines
  • CNC machining centers
  • for drilling of through-holes in solid woods and wood-based panels

Design

  • 2 v-point cutting edges with 60 degrees
  • HW-tipped
  • cylindrical shank with clamping surface
  • spiral without back guide

Advantages

  • Standard quality at low price

Notes

  • adjusting screw Ident-No. 001600 M5x10 DIN 551 for precise length adjustment included in delivery
  • adjusting screw Ident-No. 186017 M5x11,5 for Weeke quick clamping chuck must be ordered separately
  • clamping elements: combi chuck, quick-change chuck

Table- and picture caption ...

Ø D
[mm]
L2
[mm]
Ø d
[mm]
L3
[mm]
L1
[mm]
Z L/R Ident-No. Comp./ Inqu.

Dimensions entered are not listed?
Please contact our application consulting .

available from stock
available on short notice
Delivery time on request

5 40 10 20 70 2 R 186480
|
5 40 10 20 70 2 L 186481
|
6 40 10 20 70 2 R 186482
|
6 40 10 20 70 2 L 186483
|
7 40 10 20 70 2 R 186484
|
7 40 10 20 70 2 L 186485
|
8 40 10 20 70 2 R 186486
|
8 40 10 20 70 2 L 186487
|
10 40 10 20 70 2 R 186488
|
10 40 10 20 70 2 L 186489
|
5 44 10 20 77 2 R 186490
|
5 44 10 20 77 2 L 186491
|
8 44 10 20 77 2 R 186492
|
8 44 10 20 77 2 L 186493
|
