Mounting Flanges for Clamping System Ø 160 mm - tools with bore d=80 mm

for mounting of heavy tools with bore Ø 80 mm with 4 countersunk holes M 8, TK Ø 130 mm

for s-System on shaft with external thread
for clockwise and counter-clockwise rotation
indicate shaft design when placing an order
at least two separate tool/flange assemblies should be used per clamping element (reduced downtimes)
sense of rotation see drawing

	Ø d1 [mm]	L2 [mm]	L [mm]	Ø D [mm]	L1 [mm]	Remarks	Ident-No.	Comp./ Inqu.
Dimensions entered are not listed? Please contact our application consulting . available from stock available on short notice Delivery time on request
	80	18	11.8	157	45		168399	\|
	80	18	11.8	157	45	Type H	168398	\|
