Mounting Flanges for Clamping System Ø 140 mm - saw blades d=80 mm

Product

Drawing

Article

Description

Machine / Application

  • for the mounting of saw blades up to Ø 400 mm and saw plate thickness 1.8 - 2.2 mm with bore Ø 80 mm, 3 NL - Ø 22 mm, TK Ø 110 mm

Design

Advantages

Notes

  • for clockwise and counter-clockwise rotation

Table- and picture caption ...

Ø d1
[mm] 		L
[mm] 		Ø D
[mm] 		L1
[mm] 		Ident-No. Comp./ Inqu.

Dimensions entered are not listed?
Please contact our application consulting .

available from stock
available on short notice
Delivery time on request

80 10 137 28 177050
|
