Adapters with cylindrical shank - saw blades and grooving cutters
Article
Description
Machine / Application
- for PS 2000-E and draw-in collet chuck for mounting of circular saw blades and grooving cutters
Design
- secured against rotation with drive pin
Advantages
Notes
- for clockwise and counter-clockwise rotation
- length adjusting screw Ident-No. 172921 is required for PS 2000-E
- included in delivery: clamping arbor, clamping flange, cap screw and length adjusting screw for ps-System for shank Ø 16 Ident-No. 172115, shank Ø 25 Ident-No. 172113
Ø d1
[mm] |
L2
[mm] |
Ø d
[mm] |
Ø D
[mm] |
L1
[mm] |
L3
[mm] |
Dimension
[mm] |
NL |
Weight
[kg] |
Remarks | Ident-No. | Comp./ Inqu. | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Dimensions entered are not listed?
available from stock |
||||||||||||
30 | 8,0 | 16 | 60 | 78 | 43 | 30x16 | 0.495 | for plate thickness max. 6 mm | 171394 | |||
30 | 9,0 | 25 | 60 | 94 | 55 | M10 | 4/M5/48 | 0.65 | for plate thickness max. 8 mm | 167826 |
