192466 - Finger Joint Cutters HS topcoat
Technical data
Description
Machine / Application
- finger joint machines
- machines with cross-cutting device
- for longitudinal joints in soft woods
Design
- standard and topcoat
Advantages
- increased edge lives and higher wear resistance and gliding features thanks to topcoat coating
Notes
Feature | Value | |
---|---|---|
Ø D = Cutting circle diameter | 250 [mm] | |
B = Cutting width | 30 [mm] | |
b = Hub width | 28 [mm] | |
Ø d = Bore diameter | 50 [mm] | |
Z = No. of teeth | 6+6 | |
Partition = Partition | 2.8 [mm] | |
Finger joint length = Finger joint length | 6/7 [mm] | |
Number of finger joints = Number of finger joints | 10 [pc.] | |
nmax = maximum RPM | 6,000 [min-1] | |
L = Delivery Status | ||
Remarks | topcoat | |
Dimensions entered are not listed?
available from stock |
